Aerial concentric service cable With Pilot Cable

company : Zhengzhou Hesheng Cable Co., Ltd
address : Zhengzhou City, Henan Provance, China

Contact

Description

2x6mm2 Aerial concentric service cable with communication cable, 2x10mm2 Aerial concentric service cable with Pilot Cable, SNE Aerial concentric service cable In uganda

Company profile

    Established in 1998, Zhengzhou Hesheng Electric Cable Co., Ltd. is a professional manufacturer and exporter that is concerned with the design, development and production of wires and cables. We are located in Zhengzhou, with convenient transportation access. All of our products comply with international quality standards and are greatly appreciated in a variety of different markets throughout the world. We have over fifty employees, an annual sales figure that exceeds RMB 25,000,000, and are currently exporting 30% of our products worldwide. Our well-equipped facilities and excellent quality control throughout all stages of production enable us to guarantee total customer satisfaction.


    We could manufacture many types of wire & cable as different standard. For example, Electric Wire, Power Cable, Aerial Concentric Service Cable, Lift Cable, Control Cable, Welding Cable, Type of  concentric wire, etc. Aerial Concentric Service Cable is our best advantage product.
    As a result of our high quality products and outstanding customer service, we have gained a global sales network reaching the Middle East, Southeast Asia, and the United States.

    If you are interested in any of our products or would like to discuss a custom order, please feel free to contact us. We are looking forward to forming successful business relationships with new clients around the world in the near future.

Quick Details

Place of Orgin:Henan China(Mainland)
Brand Name:Hesheng Cable
Model:SNE,CNE
Voltage:600/1000V
Standard:SANS 1507
ApplicationOverhead
Material of Conductor:Hard Darwn Copper Or Aluminum
Material of Insulation:XLPE
Conductor of Pilot CableSolid Copper Wire
Insulation of Pilot CablePE or PVC
Material of Sheath:PVC
Product NameAerial concentric service cable

Aerial concentric service cable

Cable Description


2x6mm2 Aerial concentric service cable with communication cable, 2x10mm2 Aerial concentric service cable with Pilot Cable, SNE Aerial concentric service cable In uganda

Circular stranded hard drawn copper phase conductor, XPLE insulated with concentrically arranged identified neutral and bare earth conductors. Polyethlene sheathed 600/1000V service connection cable. Nylon ripcord laid under sheath. Manufactured to to SANS 1507 and NRS 063.



o Small overall diameter – concentric construction (SNE - Separate Neutral Earth)

o Lower Mass – due to smaller diameter – no steel wire armor

o Increased safety – reliable earthing

o Improved Reliability – UV stable sheath and core insulation and water blocked

o Tamper and vandal proof - unauthorized access to phase  conductor inhibited by concentric layer.

o Easy strip with nylon ripcord


Conductor:

Hard Drawn Copper Conductor – Class 2

Insulation:

LV-XLPE

Phase Color Code(SNE):

Red, Black & Bare Copper

Application:

Used for house connections , with or without coms wire.


Aerial concentric service cable Separate Neutral and Earth (SNE) Airdac 600/1000V

Physical Properties

Units

Phase Conductor Area Size

4

6

10

16

mm²

Neutral Conductor Area Size

4

6

10

16

mm²

Earth Conductor Wire(NO. X dia

3/1.35

3/1.38

3/1.78

3/2.2

mm

Phase Conductor Diam

3.8

4.3

5.1

6.2

mm

Pilot Cores Dia. Or Dummy fillers

1.2

1.2

1.2

1.2

mm

Overall Diameter

6.5

7.1

8.7

10.6

mm

Cable Mass

158

204

325

435

Kg/km

Electrical Properties

Units

Phase Conductor Resistance(DC Resistance @20℃

4.61

3.08

1.83

1.15

Ω/km

Phase Conductor Resistance (AC Resistance @90℃

5.40

3.60

2.10

1.47

Ω/km

Phase Conductor Impedance(Z)

5.49

3.70

2.19

1.39

Ω/km

Current in Air @30℃

30

40

50

70

A



Products  Characteristic & Advantage

1. Good Quanlity

2. Competitive Factory Price

3. Good After-Sale Service System

Certificate

Why Choose Us

1. Advanced process equipment

2. Competitive price and high quality

3. Excellent after-sale service

4. Attractive design and various styles

5. Powerful technology R&D team

6. Strict quality assurance system and perfect testing means

7. Advanced process equipment

8. Delivery on time

9. Have a good reputation in the domestic and overseas.

FAQ


Q: Why choose Hesheng? Any advantages?
A: The answer is Yes. There are 5 advantages.

(1) MUTUAL BENEFIT: Our offer will be reasonable, our price will be cheaper in the same quality.
(2) CUSTOMIZE: We can make the product as your request, Specification and Quality can meet your request.
(3) OEM: (1)Printing your Logo. (2)Designing your packing.
(4) MIX ORDER: We accept mix order, different model and small quantity order.
(5) AFTER SERVICE: 1 Years Guarantee.

Q: Can I order one piece for sample to test the quality?
A: Yes, We recommend to check the sample before order.


Q: If I want cheaper quality, can you produce?
A: Yes, just send us your quality details, such as the material, what cheaper parts instead etc, we will do that as your request and calculate the price.


Q: If I order big quantity, what's the good price?
A: Please send the details enquiry to us, such as the Item Number, Quantity for each item, Quality request, Logo, Payment Terms, Transport method, Discharge place etc. We will make the accurate quotation to you as soon as possible.

Packing & Delivery

1. Delivery Time

15 days after deposit


2. Packing

Our Service



    We are professional manufacturer of wire & cable for 20 years, We could produce many types of wire & cable as different standard cables or customizeas ur demand, Just show me freely if u are interesting our factory by following ways.


Skype:hab-zhu

Mobile:0086 131 0171 3571

Wechat:0086 131 0171 3571

QQ:597563375

Email:info@heshengcable.com

Web:www.heshengonline.com/en


     2x6mm2 Aerial concentric service cable with communication cable, 2x10mm2 Aerial concentric service cable with Pilot Cable, SNE Aerial concentric service cable In uganda.
